151 MFM – W
SBEM’s 151 MFM-W Electromagnetic Flow Meter is engineered for industrial precision with an accuracy of ±0.
Description
SBEM’s 151 MFM-W Electromagnetic Flow Meter is engineered for industrial precision with an accuracy of ±0.5%, supporting large diameter pipes from 15 mm up to 3000 mm and flow velocities up to 15 m/s. Constructed with stainless steel and high-grade electrode materials such as Hastelloy C and Titanium, the 151 MFM-W features a rubber or PTFE lining to ensure chemical resistance and durability. Equipped with dual-line LCD or graphical display and MODBUS-compatible digital outputs, this model offers versatile connectivity options, including HART and GSM/GPRS interfaces for real-time data transmission and SCADA integration. Its rugged IP67/IP68 rated construction and advanced features like empty pipe detection make it ideal for water treatment, petrochemical, and pharmaceutical industries globally, enhancing operational efficiency and process automation.
Features
- Maximum Range (Velocity): 15 m/s.
- Meter Sizes: 15 to 2000 mm.
- Process Connection: Flange [ANSI/AWWA/DIN] & Wafer.
- Electrode Material: SS/Hastalloy C/Tantalum/Titanium.
- Lining: Rubber/Neoprene/Hard Rubber/PTFE/Polyurethane.
- Measuring Tube Material: SS304/SS316.
- Coil Housing Material: CS/SS304/SS316.
- Two line * 16 characters LCD display.
- Integral & Remote versions.
- Bidirectional Flow Measurement.
- Built In Self Diagnosis Feature.
- Empty Pipe Detection.
- Protection Class: Sensors – IP 67 [std] / IP 68 [For remote versions only], Indicator-Converter – IP 67
- Interchangeable Converter.
- Optional Earthing Rings.
- Low Power Consumption.
