151 MFM - W
151 MFM – E
The 151 MFM-E Electromagnetic Flow Meter by SBEM delivers superior accuracy of ±0.
Description
The 151 MFM-E Electromagnetic Flow Meter by SBEM delivers superior accuracy of ±0.3% and repeatability, designed to meet demanding industrial standards. Suitable for conductive liquids with minimum conductivity of 20 μS/cm, this model supports nominal pipe sizes from 15 to 3000 mm and operates under pressures up to 16 Kg/cm². Built with corrosion-resistant materials including SS316 and optional tantalum electrodes, the 151 MFM-E ensures long-term reliability and stable measurement under extreme temperatures up to 150°C. Its user-friendly two-line backlit LCD and extensive communication capabilities—MODBUS, HART, and data logging—enable seamless integration into global process control systems. The device is widely applied in sectors such as thermal power, chemical, and naval engineering, reinforcing SBEM’s commitment to precision flow instrumentation.
Features
- Maximum Range (Velocity): 15 m/s.
- Meter Sizes: 15 to 2000 mm.
- Process Connection: Flange [ANSI/AWWA/DIN] & Wafer.
- Electrode Material: SS/Hastalloy C/Tantalum/Titanium.
- Lining: Rubber/Neoprene/Hard Rubber/PTFE/Polyurethane.
- Measuring Tube Material: SS304/SS316.
- Coil Housing Material: CS/SS304/SS316.
- Two line * 16 characters LCD display.
- Integral & Remote versions.
- Bidirectional Flow Measurement.
- Built In Self Diagnosis Feature.
- Empty Pipe Detection.
- Weights & Measures approval.
- Protection Class: Sensors – IP 67 [std] / IP 68 [For remote versions only], Indicator-Converter – IP 67
- Interchangeable Converter.
- Optional Earthing Rings.
- Low Power Consumption.
