135 LC
Paddle Type 135 LC
SBEM’s Paddle Type Level Switch Series 135 LC is a robust and modular solution for reliable level control of free-flowing solids, including powders, granules, and food grains, designed for global industrial applications.
Description
SBEM’s Paddle Type Level Switch Series 135 LC is a robust and modular solution for reliable level control of free-flowing solids, including powders, granules, and food grains, designed for global industrial applications. Featuring a weatherproof IP-65 rated enclosure made of cast aluminium and polyurethane paint, this switch ensures long-lasting performance in dusty and demanding environments. Its operating principle is based on a motor-driven paddle system, which detects material levels through torque variation when the paddle is obstructed. Key features include a PTFE lip seal to prevent dust ingress, stainless steel flexible coupling for shock resistance, adjustable or fixed shaft extensions, and field-replaceable paddle assemblies. The device offers versatile mounting options (threaded or flanged) and supports high-temperature operations up to 400°C with optional stand-offs and dust seal assemblies. The Series 135 LC is suitable for industrial applications in cement, fertilizers, PVC chips, food processing, and more. It is a critical component for accurate level measurement in global manufacturing and process industries.
Features
- Cast Aluminium polyurethane painted weather proof enclosure conforming to IP-65.
- Separate cable entries for supply and control.
- Specially designed motor which does not burn under locked rotor condition.
- Specially designed PTFE lip seal to prevent ingress of dust particles into main enclosure.
- SS flexible coupling to prevent mechanical shocks to the gear box.
- Fixed / adjustable shaft extensions to suit the functional requirement.
- Field replaceable paddle assembly, to suit various applications.
- Optional air purging facility (Inbuilt for collet extension & high temperature stand off versions and optional for other versions.)
- Optional dust seal assembly for fine particles less than 100 microns.
